Chapter 2 Preparing for Installation
Site Requirements
Table 2-7 lists the power and the heat numbers for the switch fabric modules.
Table 2-8 lists the power and the heat numbers for the 10-Gigabit Ethernet modules.
Note For all WS-X67xx modules, the values shown are for the baseboard only. When the baseboard has a CFC
or DFC3 daughter card installed, you must add the daughter card power to the baseboard power to get
the total slot power. For all other modules that support a mandatory or optional daughter card, you must
add the daughter card power to the baseboard power to get the total slot power.
WS-F6700-DFC3A
Distributed Forwarding Card 3A
3.00 126 157.5 537.86 169.35 578.35
WS-F6700-DFC3B
Distributed Forwarding Card 3B
2.7 113.40 141.75 484.08 152.42 520.51
WS-F6700-DFC3BXL
Distributed Forwarding
Card
3BXL
3.3 138.60 173.25 591.65 186.29 636.18
WS-F6700-DFC3C
Distributed Forwarding Card 3C
for use on CEF720 modules.
Supported only with Supervisor
Engine
720 and Supervisor
Engine
720-10GE
1.65 69.30 86.63 295.82 93.15 318.09
WS-F6700-DFC3CXL
Distributed Forwarding
Card
3CXL for use on CEF720
modules. Supported only with
Supervisor Engine
720 and
Supervisor Engine
720-10GE.
2.35 98.70 123.38 421.33 132.66 453.04
Table 2-6 Power Requirements and Heat Dissipation—Distributed Forwarding Cards (DFCs) (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Ta b l e 2-7 Power Requirements and Heat Dissipation—Switch Fabric Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-C6500-SFM
Switch Fabric Module
2.79 117.18 146.5 500.2 157.5 537.86
WS-X6500-SFM2
Switch Fabric Module 2
3.09 129.78 162.23 554 174.4 595.7
