2-18
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 2 Preparing for Installation
Site Requirements
Table 2-18 lists the power and the heat numbers for Optical Service modules (OSMs).
7600-ES20-GE3CXL 8.11 341 426 1454 458 1563
7600-ES20-GE3C 8.11 341 426 1454 458 1563
7600-ES+2TGCXL 7.06 297 371.25 1267.81 399.19 1363.24
7600-ES+2TG3C 6.38 268 335 1144.02 360.21 1230.13
7600-ES+4TGCXL 9.49 399 498.75 1703.23 536.29 1831.43
7600-ES+4TG3C 8.82 370 362 1236.23 497.31 1698.31
7600-ES+40G3C 9.3 391 488.75 1669.08 122.31 417.69
7600-ES+20G3CXL 7.25 305 381.25 1301.96 409.94 1399.96
7600-ES+20G3C 6.58 276 345 1178.17 370.96 1266.85
7600-ES+40G3CXL 9.97 419 523.75 1788.60 563.17 1923.23
Table 2-17 Power Requirements and Heat Dissipation—Ethernet Services
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Ta b l e 2-18 Power Requirements and Heat Dissipation—OSMs
Model Number/
Module Type
Module
Current (A)
@ 42
VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
OSM-2OC12-POS-MM, -SI,
-SL
OC-12 POS, 2-port
3.35 141 176 602 190 648
OSM-2OC12-POS-MM+, -SI+
OC-12 POS, 2-port
3.35 141 176 816 190 648
OSM-4OC12-POS-MM, -SI,
-SL
OC-12 POS, 4-port
4.78 201 251 857 270 921
OSM-4OC12-POS-SI+
OC-12 POS, 4-port
4.54 191 239 816 257 877
OSM-4OC3-POS-SI
OC-3 POS, 4-port
2.42 102 128 437 138 4.70
OSM-4OC3-POS-SI+
OC-3 POS, 4-port
2.42 102 128 437 138 4.70
OSM-8OC3-POS-SI, -SL
OC-3 POS, 8-port
3.57 150 187 640 202 688
OSM-8OC3-POS-SI+, -SL+
OC-3 POS, 8-port
3.57 150 187 640 202 688
