Chapter 4 Removing and Replacing FRUs
Replacing Backplane Modules on a Catalyst 4507R or 4510R Switch
4-26
Catalyst 4500 Series Switches Installation Guide
78-14409-08
Figure 4-21 Catalyst 4507R Backplane
Mux buffers
Clock module
130657
