Figure 16: Install Brackets for I/O-Side Mounting (C8300-2N2S-4T2X|6T)

19-inch brackets1

23-inch brackets2

#8-32 FHM screw3

Hardware Installation Guide for Cisco Catalyst 8300 Series Edge Platforms
