• It is in an n+n redundant mode, because n number of power supply modules are configured as active,
and the same number, as standby.
It also meets all the n+n redundant mode conditions:
• All power supply modules configured as active are of the same type; all modules configured as
standby are of the same type.
• A mix of AC-input and DC-input power supply modules are installed and all installed AC-input
power supply modules in the chassis are of the same capacity and have the same AC-input voltage
level.
In the sample output where Type= ac, Capacity = 2100 W for all modules. The Capacity field for
the AC-input modules also reflect that voltage is at 220 VAC.
• A mix of AC-input and DC-input power supply modules are installed, and all installed DC-input
power supply modules are configured as standby.
• Power supply modules of different capacities are installed, but the higher capacity modules are
configured as standby.
• Although the setup and configuration in this example satisfy all the conditions, a full protected state is
not guaranteed.
When the system detects power supply modules of different capacities, the system
always considers and displays the operating state as normal protected.
Note
Device# show power
Power Fan States
Supply Model No Type Capacity Status 1 2
------ -------------------- ---- -------- ------------ -----------
PS1 C9400-PWR-2100AC ac 2100 W active good good
PS2 C9400-PWR-2100AC ac 2100 W active good good
PS3 C9400-PWR-2100AC ac 2100 W active good good
PS4 C9400-PWR-2100AC ac 2100 W active good good
PS5 C9400-PWR-3200DC dc 3200 W standby good good
PS6 C9400-PWR-3200DC dc 3200 W standby good good
PS7 C9400-PWR-3200DC dc 3200 W standby good good
PS8 C9400-PWR-3200DC dc 3200 W standby good good
PS Current Configuration Mode : N+N redundant
PS Current Operating State : Normal protected
PS Slots Configured standby : PS5, PS6, PS7, PS8
Power supplies currently active : 4
Power supplies currently available : 8
Power Summary Maximum
(in Watts) Used Available
------------- ------ ---------
System Power 3505 3505
Inline Power 0 4895
------------- ------ ---------
Total 3505 8400
Other valid configuration options for the n+n mode:
System Management Configuration Guide, Cisco IOS XE Bengaluru 17.4.x (Catalyst 9400 Switches)
247
Environmental Monitoring and Power Management
Example: n+n Redundant Mode (Power Supply Modules of Different Capacities + Normal Protected State)

Cisco Catalyst 9400 Specifications

General

Product Series	Catalyst 9400 Series
Layer	Layer 2/3
Operating System	Cisco IOS XE
Switch Type	Modular
Uplink Interfaces	10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet
Stacking	No
Form Factor	Modular Chassis
Operating Temperature	0°C to 40°C (32°F to 104°F)
Redundancy	Power supplies
Security Features	MACsec
Management	Cisco DNA Center, CLI, SNMP
