About LED status colors, it is expected that there will be small variations in color intensity and hue from unit
to unit. This is within the normal range of the LED manufacturer’s specifications and is not a defect. However,
the intensity of the LED can be changed through the controller.
The AP supports dark mode to reduce visibility to the AP. You can enable the dark mode using the GUI or
CLI method in the controller. See the Information About LED States for Access Points section in the Cisco
Catalyst 9800 Series Wireless Controller Software Configuration Guide.
Note
The AP status LED indicates various conditions and is described in the following table:
Table 13: AP LED Signals
MeaningColorLED Message
Type
Boot loader status sequence:
• DRAM memory test in progress
• DRAM memory test OK
• Board initialization in progress
• Initializing the Flash file system
• Flash memory test OK
• Initializing Ethernet
• Ethernet OK
• Starting AP OS
• Initialization successful
Blinking GreenBoot loader status
sequence
This status indicates a normal operating condition. The
unit has joined a controller, but no wireless client is
associated with it.
Solid GreenAssociation status
Normal operating condition with at least one wireless client
associated with the unit
Solid Blue
Discovery or join process is in progressCycling through Green, Red,
off
This status indicates that the AP location command has
been invoked.
Rapidly cycling through
Blue, Green, Red
This status indicates that an Ethernet link is not operationalBlinking Red
Ethernet failureSolid Red
Configuration recovery is in progress (the Reset button has
been pushed for 2 to 3 seconds)
Blinking Blue
Cisco Catalyst Wireless 9163E Access Point Hardware Installation and Deployment Guide
41
Deploying the Access Point
Checking the Access Point LEDs
