Cisco CSACSE-1111-K9 - Secure Access Control Server Solution Engine User Manual

1-5
Installation Guide for Cisco Secure ACS Solution Engine 4.1
OL-9969-03
Chapter 1 Cisco Secure ACS Solution Engine Overview
ACS SE Hardware Description
Back Panel Features for the Cisco 1113
The back panel for the Cisco 1113 contains the AC power receptacle, Ethernet connectors, indicator
LEDs, and a serial port.
Figure 1-3 shows the back-panel features.
5 Unit Identification Button To enable the Unit Identification LED, push the Unit
Identification Button.
When the Unit identification button is on, the Unit
Identification LEDs on the front and back panels flash
blue. This enables you to go behind the unit and look at the
flashing blue light on the back You can turn off the flashing
LED on the back of the unit off by pressing the Unit
Identification button on the back panel.
To turn off the Unit Identification LED, when the LED is
on, push the Unit Identification Button.
6 Unit Identification LED The Unit Identification LED has the following states:
Off = System power is off, the system ID button has not
been pushed, and there is no fault assertion condition (the
system cover is on the device and there is no fault
condition).
Flashing Blue = When the system ID button is pushed, the
Unit Identification LED flashes blue if the system is in
either standby mode or system power is on.
Solid Blue = System power is on, the system cover is on the
device, and there is no fault assertion condition. The
system ID button has not been pushed.
Flashing Amber = The system is on standby power, there
is a fault assertion condition (for example, the cover has
been removed from the device), and the system ID button
has not been pushed.
7 USB port (not supported) Universal Serial Bus port. Do not use.
No. Switch or LED Indicator Description
