Cisco CSACSE-1111-K9 - Secure Access Control Server Solution Engine User Manual

3-4
Installation Guide for Cisco Secure ACS Solution Engine 4.1
OL-9969-03
Chapter 3 Installing and Configuring Cisco Secure ACS Solution Engine 4.1
Installing the Cisco 1113 in a Rack
Figure 3-2 Removing the Chassis Rail Mount
Step 2 See Figure 3-3. Slide the white tab (1) in the direction of its arrow and slide out the chassis rail mount
part. (Set it aside for attaching to the chassis in the next step.)
Figure 3-3 Sliding the Chassis Rail Mount Release Tab
Step 3 Align the holes in the chassis rail mount to the pegs on the chassis (1 and 2 in Figure 3-4).
1
2
3
154629
1
154625
