The figure below, "Cisco CSR 1000v I/O Routing Between vNIC of Guest OS and Hardware NIC of Host",

shows the I/O routing options.

Figure 1: Cisco CSR 1000v I/O Routing Between vNIC of Guest OS and Hardware NIC of Host

Drivers

The following table indicates the drivers required to support various I/O modes.

Table 3: Driver Support for I/O Modes

Cisco CSR1000v DriversMode

•

VMXNET3 (ESXi)

•

Virtio (KVM)

•

VIF-netfront (Xen)

•

NetVSC (Hyper-V)

Para Virtual

•

ixgbe (for Intel 10 gig NIC)

•

enic (for Cisco VIC)

PCI Passthrough

•

ixgbevf

SR-IOV
