Installing CSL Regular Licenses for Cisco IOS XE 3.13S and Later
In Cisco IOS XE 3.13S and later, including IOS XE Denali 16.3 and later, the Cisco CSR 1000v first boots
in limited mode with the AX feature set enabled and the maximum throughput limited to 100 Kbps. You can
generate multiple licenses for the Cisco CSR 1000v from one PAK. The purchased PAK determines the
number of licenses you can generate.
Repeat these steps for each license available for your PAK.
If you installed a license that supports a maximum throughput of 10 Gbps, then additional configuration
is required to support the 10 Gbps interface. See Configuring an Interface for 10 Gbps Maximum
Throughput, on page 161.
Note
SUMMARY STEPS
1.
Obtain the PAK.
2.
enable
3.
show license udi
4.
Convert the PAK to a license by entering the PAK and the UDI into the Cisco Product License registration
portal: http:/www.cisco.com/go/license
5.
license install stored-location-url
6.
configure terminal
7.
license boot level {ipbase | security | ax | appx}
8.
end
9.
write memory
10.
reload
11.
show license detail
12.
platform hardware throughput level MB{10 | 100 | 1000 | 10000 | 250 | 2500 | 50 | 500 | 5000}
DETAILED STEPS
Step 1
Obtain the PAK.
The PAK is provided to you when you order or purchase the right to use a feature set.
•
The PAK serves as a receipt and is used as part of the process to obtain a license.
Step 2
enable
Enables privileged EXEC mode.
•
Enter your password if prompted.
Step 3
show license udi
Displays all the UDI values that can be licensed in a system.
•
You need the UDI of the device as part of the process to obtain a license.
Cisco CSR 1000v Series Cloud Services Router Software Configuration Guide
159
Installing Cisco CSR 1000v Licenses
Installing CSL Regular Licenses for Cisco IOS XE 3.13S and Later
