DescriptionProperty
(Optional) Configures the IP address used for remote
management of the Cisco CSR 1000v by the REST
API or by the Cisco Prime Network Services
Controller. The address must be in the same subnet
as the management interface address.
Beginning with Cisco IOS XE 3.13S, this
option is not used if configuring the shared
management interface to support REST API.
Note
remote-mgmt-ipv4-addr
(Cisco 3.16S2 and later)
Configures the Resource Template.
Possible values: default, service_plane_medium,
service_plane_heavy
resource-template
Example ovf-env.xml File
<?xml version="1.0" encoding="UTF-8"?>
<Environment
xmlns:oe="http://schemas.dmtf.org/ovf/environment/1">
<PropertySection>
<Property oe:key="com.cisco.csr1000v.license.1" oe:value="security"/>
<Property oe:key="com.cisco.csr1000v.console.1" oe:value="serial"/>
<Property oe:key="com.cisco.csr1000v.config-version.1" oe:value="1.0"/>
<Property oe:key="com.cisco.csr1000v.domain-name.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.enable-scp-server.1" oe:value="False"/>
<Property oe:key="com.cisco.csr1000v.enable-ssh-server.1" oe:value="False"/>
<Property oe:key="com.cisco.csr1000v.hostname.1" oe:value="lab"/>
<Property oe:key="com.cisco.csr1000v.license.1" oe:value="ax"/>
<Property oe:key="com.cisco.csr1000v.login-password.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.login-username.1" oe:value="lab"/>
<Property oe:key="com.cisco.csr1000v.mgmt-interface.1" oe:value="GigabitEthernet1"/>
<Property oe:key="com.cisco.csr1000v.mgmt-ipv4-addr.1" oe:value="172.25.223.251/25"/>
<Property oe:key="com.cisco.csr1000v.mgmt-ipv4-gateway.1" oe:value="172.25.223.129"/>
<Property oe:key="com.cisco.csr1000v.mgmt-ipv4-network.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.mgmt-vlan.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.pnsc-agent-local-port.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.pnsc-ipv4-addr.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.pnsc-shared-secret-key.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.privilege-password.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.remote-mgmt-ipv4-addr.1" oe:value=""/>
<Property oe:key="com.cisco.csr1000v.resource-template.1"
oe:value="service_plane_medium"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0001" oe:value="logging buffered
10000"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0002" oe:value="hostname uut-ovf"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0003" oe:value="ip domain-name
cisco.com"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0004" oe:value="crypto key generate
rsa modulus 1024"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0005" oe:value="interface
GigabitEthernet2"/>
<Property oe:key="com.cisco.csr1000v.ios-config-0006" oe:value="ip address 10.0.0.5
255.255.255.0"/>
Cisco CSR 1000v Series Cloud Services Router Software Configuration Guide
128
Installing the Cisco CSR 1000v in KVM Environments
Example ovf-env.xml File
