5-36 D9865 Satellite Receiver Installation and Operation Guide 4035197 Rev C
Setting up the Video, Continued
6. Select the Wide Screen Signalling output mode. It is used to select how the
receiver affects PAL WSS when it is present in the VBI. The table below
describes each of the options. The default is Auto.
7. Select Enable Banner Display to display the signal status and other information
at the top of the screen.
8. The Video Status section displays the current video information, such as the
aspect ratio mode, encoding format, and bit rate.
9. Click Apply.
WSS Mode Description
Passthrough Passes WSS (unmodified, as received by the D9865
receiver) on VBI LIne 23 when present
Auto:Create Creates WSS to output the correct aspect ratio, when
performing aspect ratio conversion, otherwise it is
passed through.
Auto:Modify Modifies WSS to output the correct aspect ratio, when
performing aspect ratio conversion, otherwise it is
passed through
Suppress Disables Line 23 VBI processing. WSS is not output on
line 23.
