4-26 D9865 Satellite Receiver Installation and Operation Guide 4035197 Rev C
Setting Up the Satellite Dish
To Set Up the Dish
The Dish Setup menu provides graphical assistance for dish positioning. This menu
can be set to two modes: User Mode (default) or Installer Mode. The User mode
allows you to select from stored Satellite Numbers, which are stored satellite
locations, as stored in the dish motor, but does not provide any dish control.
Proceed as follows to set up the dish:
1. From the Setup Menu, select Dish Setup and press OK. By default, the Dish
Setup screen is displayed in User mode.
2. The table at the top displays the current configurations.
3. The following table describes each of the options in User mode:
Selection Options Description
Satellite Number 1 to 255 Number identifying the saved satellite
location as defined by the dish motor
manufacturer.
User Action None No action is performed.
Goto Satellite Moves the dish to the selected pre-stored
satellite position. Satellite positions are stored
in the dish motor, if supported, not in the
receiver.
