5-46 D9865 Satellite Receiver Installation and Operation Guide 4035197 Rev C
Setting Up IP Routing
To Set Up IP Routing
Proceed as follows to configure the IP Routing settings:
1. From the user interface of the D9865, click System Settings > System, expand IP
Settings and then click IP Routing. The IP Routing page is displayed.
2. The MPE Data Filter Mode sets whether all the MPE data is forwarded
(Forward All) via the Gateway. It can forward up to 5 PIDs at the maximum bit
rates shown in the following table. Otherwise, select Forward None.
3. Set the MPE Optimization setting. Select High Bitrate (default) to accumulate
the IP packets before they are processed in short bursts, increasing the allowable
bit rate of MPE data. Select Low Jitter to emit the IP packets in a constant
stream, resulting in low latency.
MPE Bit Rate No
Decoding
5 Mbps SD
Video Decoded
20 Mbps HD
Video Decoded
Multicast 30 Mbps 20 Mbps 15 Mbps
Unicast 20 Mbps 15 Mbps 10 Mbps
