4035197 Rev C D9865 Satellite Receiver Installation and Operation Guide A-7
Audio Outputs
Analog Audio Output
Digital Audio S/PDIF Output
VBI
Parameter
Specification
Number of Channels 1 stereo pair/2 mono channels
Connector Type RCA
Output Level Unbalanced, 2 V rms ± 10% at 0 dBFS
Audio Decompression MPEG 1 Layer 2, Dolby Digital Plus, HE-
AAC
Parameter
Specification
Connector Type RCA
Output Impedance 75Ω +/-20%, from 0.1 MHz to 6.0 MHz
Signal Amplitude 0.5V +/-20% at 75Ω
Parameter
Specification
NTSC Lines 10 to 22 fields 1 and 2
PAL Lines 7 to 22 fields 1 and 2
WST, WSS, VPS
