4-18 D9865 Satellite Receiver Installation and Operation Guide 4035197 Rev C
Setting up Tuning / Preset
To Set Up Tuning/Preset Parameters
The Tuning/Preset menu is used to display and configure the current settings.
Proceed as follows to set up the tuning/preset:
1. From the Setup Menu screen, select Tuning / Preset and press OK.
2. The following table describes each of the available options:
Selection Options Description Default
Modulation Type DVB-S Enter the modulation scheme. DVB-S2
DVB-S2
Downlink (Freq) Enter
number
For C-Band:
Downlink Freq = LO Freq - L-Band Freq.
For Ku-Band:
Downlink Freq = LO Freq + L-Band Freq.
12.3
Symbol Rate 1.0 to 45.0
1.0 to 31.0
Range for DVB-S in MS/s.
Range for DVB-S2 in MS/s.
30.0
NetId Enter
number
Obtain the number from your service
provider.
1
