4035197 Rev C D9865 Satellite Receiver Installation and Operation Guide 5-45
Setting Up IP Information
To Configure Management and Data Port Settings
Proceed as follows to configure management and data port settings:
1. From the user interface of the D9865, click System Settings > System > IP
Settings. The IP Settings page is displayed.
2. For the Management and Data Port Settings, set the following parameters:
Selection Description
IP Address Sets the IP Address for its participation
in a Network environment. The IP
Address is 12 digits in length
(###.###.###.###).
IP Mask Sets Subnet Mask for its participation in
a Network environment. You can enter
a value in the range from 8 to 32.
Gateway Address Sets the Network Gateway Address on
the Network, used to expose the
receiver to a WAN.
