DVB-S2 Error Rate Performance ES/No (C/N) Ratio
DVB-S2 Error Rate Performance Es/No (C/N) Ratio
Note: “Typical performance” was measured with Pilots On. Pilots On is highly
recommended as the performance values typically degrade up to 0.9 dB with Pilots
Off. Pilots On must be used for 8PSK 3/5, 8PSK 2/3 and 8PSK 3/4.
Mode Simulated Es/No (dB) for FEC
Frame length = 64,800
Typical Performance (dB) in
Linear Channel and IF Loop
Configuration
QPSK 1/2 1.00 1.2
QPSK 3/5 2.23 2.4
QPSK 2/3 3.10 3.2
QPSK 3/4 4.03 4.2
QPSK 4/5 4.68 4.8
QPSK 5/6 5.18 5.3
QPSK 8/9 6.20 6.4
QPSK 9/10 6.42 6.6
8PSK 3/5 5.50 5.8
8PSK 2/3 6.62 6.8
8PSK 3/4 7.91 8.1
8PSK 5/6 9.35 9.6
8PSK 8/9 10.69 10.9
8PSK 9/10 10.98 11.3
