Administration: Discovery
Discover - LLDP
134 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
9
- 4-Wire Power via MDI—(relevant to PoE ports supporting 60W PoE) Proprietary
Cisco TLV defined to support power over Ethernet that allow for 60 watts power
(standard support is up to 30 watts).
Management Address Optional TLV
• Advertisement Mode—Select one of the following ways to advertise the IP
management address of the device:
- Auto Advertise—Specifies that the software automatically chooses a management
address to advertise from all the IP addresses of the device. In case of multiple IP
addresses, the software chooses the lowest IP address among the dynamic IP
addresses. If there are no dynamic addresses, the software chooses the lowest IP
address among the static IP addresses.
- None—Do not advertise the management IP address.
- Manual Advertise—Select this option and the management IP address to be
advertised. We recommend you select this option when the device is configured
with multiple IP addresses.
• IP Address—If Manual Advertise was selected, select the Management IP address
from the addresses provided.
802.1 VLAN and Protocol
• PVID—Select to advertise the PVID in the TLV.
• Port and Protocol VLAN ID—Enter the protocol-based VLANs enabled on the port.
• VLAN ID—Select which VLANs will be advertised.
• Protocol IDs—Select which protocols will be advertised.
• Selected Protocol IDs—Select the protocols to be used in the Protocols IDs box and
move them to the Selected Protocols ID box.
STEP 3 Enter the relevant information, and click Apply. The port settings are written to the Running
Configuration file.
