Cisco SG350-10MP Administration Guide

Smart Network Application (SNA)
Search
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 503
25
User-Defined Tags
You can create new tags and add them manually to selected elements in the topology in the
Tags section of the right-hand information.
To create a new tag perform the following steps:
STEP 1 In the Tags section, click in the Add tag name text box and enter a tag name.
STEP 2 Click ADD+. The tag name is then displayed. The below shows that the tag first_floor has
been created.
You may add tags that have the same names as built-in tags. These tags appear similar to user-
defined tags and you can remove them at any time. Since these tags are distinct from the built-
in tags, it is possible for tags with the same name to appear twice on a single element as long
as one of them is user-defined and the other is built-in.
To add a tag to a device perform the following steps:
STEP 1 Select the device.
STEP 2 In the Tag section, click the Add tag name text box. A list of tags is displayed.
STEP 3 Select the tag to be applied to the device.
Search
Use the search functionality to locate specific devices in the Topology view.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
