Status and Statistics
802.1X EAP
54 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
5
802.1X EAP
The 802.1x EAP page displays detailed information regarding the EAP (Extensible
Authentication Protocol) frames that were sent or received. To configure the 802.1X feature,
see the (Security > 802.1x) Properties page.
To view the EAP Statistics and/or set the refresh rate:
STEP 1 Click Status and Statistics > 802.1x EAP.
STEP 2 Select the Interface that is polled for statistics.
STEP 3 Select the Refresh Rate (time period) that passes before the EAP statistics are refreshed.
The values are displayed for the selected interface.
• EAPOL EAP Frames Received—Valid EAPOL frames received on the port.
• EAPOL Start Frames Received—Valid EAPOL start frames received on the port.
• EAPOL Logoff Frames Received—EAPOL Logoff frames received on the port.
• EAPOL Announcement Frames Received—EAPOL Announcement frames received
on the port.
• EAPOL Announcement Request Frames Received—EAPOL Announcement
Request frames received on the port.
• EAPOL Invalid Frames Received—EAPOL invalid frames received on the port.
• EAPOL EAP Length Error Frames Received—EAPOL frames with an invalid
Packet Body Length received on this port.
• MKPDU Frames with unrecognized CKN Received—EAP frames with
unrecognized CKN received on this port.
• MKPDU Invalid Frames Received—MKPDU invalid frames received on the port.
• Last EAPOL Frame Version—Protocol version number attached to the most recently
received EAPOL frame.
• Last EAPOL Frame Source—Source MAC address attached to the most recently
received EAPOL frame.
• EAPOL EAP Supplicant Frames Transmitted—EAPOL EAP Supplicant frames
transmitted on the port.
• EAPOL Start Frames Transmitted—EAPOL Start frames transmitted on the port.
