Cisco SG350-10MP Administration Guide

Quality of Service
QoS Basic Mode
428 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
23
STEP 5 Click Apply to save the settings.
Click Restore Default Flows to restore the default flows.
TCP Congestion Avoidance
The TCP Congestion Avoidance page enables activating a TCP congestion avoidance
algorithm. The algorithm breaks up or avoids TCP global synchronization in a congested
node, where the congestion is due to various sources sending packets with the same byte
count.
To configure TCP congestion avoidance:
STEP 1 Click Quality of Service > General > TCP Congestion Avoidance.
STEP 2 Click Enable to enable TCP congestion avoidance, and click Apply.
QoS Basic Mode
This section covers the following topics:
•Overview
• Global Settings
• Interface Settings
Overview
In QoS Basic mode, a specific domain in the network can be defined as trusted. Within that
domain, packets are marked with 802.1p priority and/or DSCP to signal the type of service
they require. Nodes within the domain use these fields to assign the packet to a specific output
queue. The initial packet classification and marking of these fields is done in the ingress of the
trusted domain.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
