Quality of Service
QoS Statistics
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 443
23
- Permit Any—Select to forward packets on the interface if they do not match any
policy.
NOTE Permit Any can be defined only if IP Source Guard is not activated on the
interface.
STEP 7 Click Apply. The QoS policy binding is defined, and the Running Configuration file is
updated.
QoS Statistics
From these pages you can manage the Single Policer, Aggregated Policer, and view queues
statistics.
Policer Statistics
A Single Policer is bound to a class map from a single policy. An Aggregate Policer is bound
to one or more class maps from one or more policies.
Viewing Single Policer Statistics
The Single Policer Statistics page indicates the number of in-profile and out-of-profile packets
that are received from an interface that meet the conditions defined in the class map of a
policy.
NOTE This page is not displayed when the device is in Layer 3 mode.
To view policer statistics:
STEP 1 Click Quality of Service > QoS Statistics > Single Policer Statistics.
This page displays the following fields:
• Interface—Statistics are displayed for this interface.
• Policy—Statistics are displayed for this policy.
• Class Map—Statistics are displayed for this class map.
• In-Profile Bytes—Number of in-profile bytes received.
• Out-of-Profile Bytes—Number of out-profile bytes received.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
