Status and Statistics
ACL
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 55
5
• EAPOL Logoff Frames Transmitted—EAPOL Logoff frames transmitted on the
port.
• EAPOL Announcement Frames Transmitted—EAPOL Announcement frames
transmitted on the port.
• EAPOL Announcement Request Frames Transmitted—EAPOL Announcement
Request frames transmitted on the port.
• EAPOL EAP Authenticator Frames Transmitted—EAP Authenticator frames
transmitted on the port.
• EAPOL MKA Frames with No CKN Transmitted—MKA frames with no CKN
transmitted on the port.
STEP 4 To clear statistics counters:
• Click View All Interfaces Statistics to view the counters of all interfaces.
• Click Clear Interface Counters to clear the counters of all interfaces.
ACL
When the ACL logging feature is enabled, an informational SYSLOG message is generated
for packets that match ACL rules.
To view the interfaces on which packets forward or rejected based on ACLs:
STEP 1 Click Status and Statistics > ACL.
STEP 2 Select the Refresh Rate (time period in seconds) that passes before the page is refreshed. A
new group of interfaces is created for each time period.
The following information is displayed:
• Global Trapped Packet Counter—Number of packets trapped globally due to lack of
resources.
• Trapped Packets—Port/LAG Based—The interfaces on which packets forwarded or
rejected based on ACL rules.
• Trapped Packets—VLAN Based—The VLANs on which packets forwarded or
rejected based on ACL rules.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
