Cisco SG350-10MP Administration Guide

Quick Getting Started
98DX4203, 98DX4204, 98DX4210, 98DX4211, and 98DX4212Switch Features
28 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
1
Front Panel
The ports, LEDs, and Reset button are located on the front panel of the switch as represented
in the following illustrations. Not all SKUs are displayed below. Rather a representative group
is displayed.
SG350-52P
SF350X-24PD
SG350XG-2F10
SG550XG-48T
The following components are found on the front panel of the device:
• USB Port—The USB port connects the switch to a USB device so that you can save
and restore the configuration files, firmware images, and SYSLOG files through the
connected USB device.
• RJ-45 Ethernet Ports—The RJ-45 Ethernet ports connect network devices, such as
computers, printers, and access points, to the switch.
• Multigigabit Ethernet Ports—Highlighted in blue, these ports support speeds of 100
Mbps, 1 Gbps, and 2.5 Gbps, on Cat 5e cables. Much of the cabling deployed
worldwide is limited to 1 Gbps at 100 meters. Cisco Multigigabit Ethernet enables
speeds up to 2.5 Gbps on the same infrastructure without replacing a cable.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
