Cisco SG350-10MP Administration Guide

Spanning Tree
MSTP Interface Settings
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 257
13
- If the link partner is using STP, the displayed port mode is STP.
• Type—Displays the MST type of the port.
- Boundary—A Boundary port attaches MST bridges to a LAN in a remote region. If
the port is a boundary port, it also indicates whether the device on the other side of
the link is working in RSTP or STP mode.
- Internal—The port is an internal port.
• Designated Bridge ID—Displays the ID number of the bridge that connects the link or
shared LAN to the root.
• Designated Port ID—Displays the Port ID number on the designated bridge that
connects the link or the shared LAN to the root.
• Designated Cost—Displays the cost of the port participating in the STP topology. Ports
with a lower cost are less likely to be blocked if STP detects loops.
• Remain Hops—Displays the hops remaining to the next destination.
• Forward Transitions—Displays the number of times the port has changed from the
Forwarding state to the Discarding state.
STEP 6 Click Apply. The Running Configuration file is updated.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
