Cisco SG350-10MP Administration Guide

IP Configuration: RIPv2
How Rip Operates on the Device
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 338
18
Causes RIP to use the predefined default metric value for the propagated route
configuration.
• Transparent (default)
Causes RIP to use the routing table metric as the RIP metric for the propagated route
configuration.
This results in the following behavior:
- If the metric value of a route is equal to or less than 15, this value is used in the RIP
protocol when advertising this route.
- If the metric value of a static route is greater than 15, the route is not advertised to
other routers using RIP.
• User Defined Metric
Causes RIP to use the metric value entered by the user.
Using RIP in Network with Non-Rip Devices
Static route configuration and connected interfaces must be taken into account when using
RIP. This is shown in the following, which illustrates a network where some routers support
RIP and others do not.
A Network with RIP and non-RIP Routers

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
