Cisco SG350-10MP Administration Guide

Security
RADIUS
326 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
17
• Authentication Port—Enter the UDP port number of the RADIUS server port for
authentication requests.
• Accounting Port—Enter the UDP port number of the RADIUS server port for
accounting requests.
• Retries—Select User Defined and enter the number of requests that are sent to the
RADIUS server before a failure is considered to have occurred. If Use Default is
selected, the device uses the default value for the number of retries.
• Dead Time—Select User Defined and enter the number of minutes that must pass
before a non-responsive RADIUS server is bypassed for service requests. If Use
Default is selected, the device uses the default value for the dead time. If you enter 0
minutes, there is no dead time.
• Usage Type—Enter the RADIUS server authentication type. The options are:
- Login—RADIUS server is used for authenticating users that ask to administer the
device.
- 802.1X—RADIUS server is used for 802.1x authentication.
- All—RADIUS server is used for authenticating user that ask to administer the
device and for 802.1X authentication.
STEP 6 Click Apply. The RADIUS server definition is added to the Running Configuration file of the
device.
STEP 7 To display sensitive data in plaintext form on the page, click Display Sensitive Data As
Plaintext.
RADIUS Server
The device can be configured as a RADIUS server. To do this, use the GUI pages described
below.
RADIUS Server Global Settings
To set the RADIUS server global parameters:
STEP 1 Click Security > RADIUS Server > RADIUS Server Global Settings.
STEP 2 Enter the following parameters:
• RADIUS Server Status—Check to enable the RADIUS server feature status.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
