Cisco SG350-10MP Administration Guide

Security
Storm Control
350 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
17
Storm Control
To define Storm Control:
STEP 1 Click Security > Storm Control > Storm Control Settings.
STEP 2 Select a port and click Edit.
STEP 3 Enter the parameters.
• Interface—Select the port for which storm control is enabled.
Unknown Unicast Storm Control
• Storm Control State—Select to enable Storm Control for Unicast packets.
• Rate Threshold—Enter the maximum rate at which unknown packets can be
forwarded. This value can be entered by Kbits/sec or By percentage of the total
available bandwidth.
• Trap on Storm—Select to send a trap when a storm occurs on a port. If this is not
selected, the trap is not sent.
• Shutdown on Storm—Select to shutdown a port when a storm occurs on the port. If
this is not selected extra traffic is discarded.
Multicast Storm Control
• Storm Control State—Select to enable Storm Control for Multicast packets.
• Multicast Type—Select one of the following types of Multicast packets on which to
implement storm control:
- All—Enables storm control on all Multicast packets on the port.
- Registered Multicast—Enables storm control only on registered Multicast addresses
on the port.
- Unregistered Multicast—Enables only unregistered Multicast storm control on the
port.
• Rate Threshold—Enter the maximum rate at which unknown packets can be
forwarded. This value can be entered by Kbits/sec or By percentage of the total
available bandwidth.
• Trap on Storm—Select to send a trap when a storm occurs on a port. If this is not
selected, the trap is not sent.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
