Cisco SG350-10MP Administration Guide

Security: 802.1X Authentication
Supplicant Credentials
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 375
18
To preview the login or success message, click Preview.
To set the default language of the GUI interface as the default language for Web-based
authentication, click Set Default Display Language.
Supplicant Credentials
This page enables creating and configuring credentials that can be used by an interface
configured as an 802.1x supplicant.
To add a supplicant’s credentials:
STEP 1 Click Security > 802.1X Authentication > Supplicant Credentials.
STEP 2 Click Add.
STEP 3 Enter the following fields:
• Credential Name—Name by which to identify the credential.
• User Name—Enter the user name associated with the credential name.
• Description—Enter text describing the user.
• Password—Select the type of password: Encrypted or Plaintext and add the
password.
STEP 4 Click Apply and the settings are saved to the Running Configuration file.
MAC-Based Authentication Settings
This page enables you to configure various setting to apply to MAC-based authentication.
To configure MAC-based authentication:
STEP 1 Click Security > 802.1X Authentication > MAC-Based Authentication Settings
STEP 2 Enter the following fields:
• MAC Authentication Type—Select one of the following options:

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
