Status and Statistics
RMON
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 77
5
RMON Events Control
You can control the occurrences that trigger an alarm and the type of notification that occurs.
This is performed as follows:
• Events Page—Configures what happens when an alarm is triggered. This can be any
combination of logs and traps.
• Alarms Page—Configures the occurrences that trigger an alarm.
To define RMON events:
STEP 1 Click Status and Statistics > RMON > Events.
This page displays previously defined events.
The fields on this page are defined by the Add RMON Events dialog box except for the Time
field.
• Time—Displays the time of the event. (This is a read-only table in the parent window
and cannot be defined).
STEP 2 Click Add.
STEP 3 Enter the parameters.
• Event Entry—Displays the event entry index number for the new entry.
• Community—Enter the SNMP community string to be included when traps are sent
(optional). Note that the community must be defined using the Notification Recipients
pages for the trap to reach the Network Management Station.
• Description—Enter a name for the event. This name is used in the Add RMON Alarm
page to attach an alarm to an event.
• Notification Type—Select the type of action that results from this event. Values are:
- None—No action occurs when the alarm goes off.
- Log (Event Log Table)—Add a log entry to the Event Log table when the alarm is
triggered.
- Trap (SNMP Manager and Syslog Server)—Send a trap to the remote log server
when the alarm goes off.
- Log and Trap—Add a log entry to the Event Log table and send a trap to the remote
log server when the alarm goes off.
• Owner—Enter the device or user that defined the event.
