DescriptionSignalPin
Module transmitter faultTX_Fault2
Transmitter disableTX_Disable3
Two-wire serial interface data lineSDA4
Two-wire serial interface clockSCL5
Module absentMOD_ABS6
Rate select 0; optionally controls SFP+ module receiverRS07
Receiver loss of signal indicationRX_LOS8
Rate select 1; optionally controls SFP+ transmitterRS19
Module receiver groundVeeR10
Module receiver groundVeeR11
Receiver inverted data outputRD-12
Receiver non-inverted data outputRD+13
Module receiver groundVeeR14
Module receiver 3.3-V supplyVccR15
Module transmitter 3.3-V supplyVccT16
Module transmitter groundVeeT17
Transmitter non inverted data inputTD+18
Transmitter inverted data inputTD-19
Module transmitter groundVeeT20
Network Port LEDs
Each network port on the vEdge 5000 router has two LEDs—the activity LED and the link LED. See Figures
1 through 3.
Figure 1: LEDs on the 8x1GE Copper Rj45 NIM
Hardware Installation Guide for vEdge Routers
228
vEdge 5000 Router
Ports and Connectors
