Cisco vEdge Series User Manual

Table 17:
SpecificationItem
MIMO, dipole swivelAntenna type
10 WattsInput power
SMA maleConnector
50 OhmsNominal
impedance
OmnidirectionalRadiation pattern
698MHz to 960MHz and 1710MHz to 2700MhzFrequency range
F (–40°C to 85°C)Temperature range
Length: 6.37 in. (16.19 cm)
Width: 0.9 in. (2.38 cm)
Depth: 0.63 in. (1.59 cm)
Antenna
dimensions
Noncondensing, 65°C, 95% RHHumidity
Front and Rear Panel Components
This article describes the components on the front and rear panels of the vEdge 100m router. See At a Glance
for the exact location of these components on the router.
Front Panel LEDs
The vEdge 100m router has five chassis status LEDs located on the front panel. Table 1 describes the LEDs
, their color and states, and the status they indicate.
Table 18:
StatusColorLED
• Off: System is not on
• Green: System is healthy and operational
• Red: Power supply fault
Green/RedPower
Hardware Installation Guide for vEdge Routers
57
vEdge 100m Router
Front and Rear Panel Components

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
