SpecificationItem
Length: 6.37 in. (16.19 cm)
Width: 0.9 in. (2.38 cm)
Depth: 0.63 in. (1.59 cm)
Antenna
dimensions
Noncondensing, 65°C, 95% RHHumidity
Wi-Fi Specifications
The vEdge 100wm router provides the following Wi-FI capabilities:
• Embedded Wi-Fi radio for access point functionality
• Wi-Fi radio configurable for 2.4-GHz or 5.0-GHz operation
• Supports IEEE 802.11a, 802.11b, 802.11g, 802.11 n, and 802.11ac protocols
• Supports channel bandwidth of 20 MHz, 40 MHz, and 80 MHz
• Supports IEEE 802.11h DFS channels
• 3x3 MIMO with three spatial streams
• Supports up to four different SSIDs
• Supports up to 50 concurrent clients
• Supports wireless security and authentication:
• Personal and enterprise WPA/WPA2
• AES/CCMP encryption
• TKIP encryption
• Internal embedded antennas
Front and Rear Panel Components
This article describes the components on the front and rear panels of the vEdge 100wm router. For the exact
location of these components on the router, see At a Glance .
Front Panel LEDs
The vEdge 100wm router has five chassis status LEDs located on the front panel. Table 1 describes the LEDs,
their color and states, and the status they indicate.
Hardware Installation Guide for vEdge Routers
89
vEdge 100wm Router
Front and Rear Panel Components
