Cisco vEdge Series User Manual

DescriptionvEdge5000
Router
vEdge
2000
Router
vEdge
1000
Router
Viptela Part
Number
Manufacturer & Part
Number
• SFP+ transceiver
• LC-type transceiver
• Short-reach 850-nm optics for
multi-mode fiber for dual-rate 1
Gbps/10 Gbps applications
Note : The SFP+ ports of the 10-Gigabit
Ethernet PIM support a rate of 10 Gbps
only. 1 Gbps is not supported.
XXFinisar
FTLX8571D3BCV
• SFP+ transceiver
• LC-type connector
• Long-reach 1310-nm optics for
single-mode fiber up to 10 km for
dual-rate 1 Gbps/10 Gbps applications
Note: The SFP+ ports on the 10-Gigabit
Ethernet PIM support a rate of 10 Gbps
only. 1 Gbps is not supported.
XXFinisar
FTLX1471D3BCV
• SFP+ transceiver
• LC-type connector
• Long-reach 1310-nm optics for
single-mode fiber up to 10 km for
10-Gbps applications
XXSFP+-10GE-LRFinisar
FTLX1471D3BCL
Ports and Connectors
The vEdge 5000 router supports three types of ports: network ports, management port, and console port.
Network Ports (SFP Ports)
The 8x1-Gigabit Ethernet SFP NIM module support 1-Gbps SFP module. The 4x10-Gigabit Ethernet SFP+
NIM module supports 10-Gbps SFP+ module.
Table 1 provides the pinout information for the NIM SFP/SFP+ port connector. The SFP/SFP+ ports comply
with the SFP/SFP+ MSA standards.
Table 79:
DescriptionSignalPin
Module transmitter groundVeeT1
Hardware Installation Guide for vEdge Routers
227
vEdge 5000 Router
Ports and Connectors

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
