DescriptionvEdge5000
Router
vEdge
2000
Router
vEdge
1000
Router
Viptela Part
Number
Manufacturer & Part
Number
• SFP+ transceiver
• LC-type connector
• Long-reach 1310-nm optics for
single-mode fiber up to 10 km for
10-Gbps applications
XXSFP+-10GE-LRFinisar
FTLX1471D3BCL
Ports and Connectors
The vEdge 1000 router supports three types of ports: network ports (also called SFP ports), management port,
and console port.
Network Ports (SFP Ports)
The built-in Gigabit Ethernet network ports on the vEdge 1000 router support 1-Gbps SFP transceiver modules.
Table 1 provides the pinout information for the built-in SFP port connector. The SFP ports comply with the
SFP MSA standards.
Table 37:
DescriptionSignalPin
Module transmitter groundVeeT1
Module transmitter faultTX_Fault2
Transmitter disableTX_Disable3
Two-wire serial interface data lineSDA4
Two-wire serial interface clockSCL5
Module absentMOD_ABS6
Rate select 0; optionally controls SFP module receiverRS07
Receiver loss of signal indicationRX_LOS8
Rate select 1; optionally controls SFP transmitterRS19
Module receiver groundVeeR10
Module receiver groundVeeR11
Receiver inverted data outputRD-12
Receiver non-inverted data outputRD+13
Hardware Installation Guide for vEdge Routers
120
vEdge 1000 Router
Ports and Connectors
