Cisco vEdge Series User Manual

Table 5 describes the LEDs on the management port.
Table 83:
State and DescriptionColorLED
• Blinking—There is link activity.
• Off—There is no link activity.
AmberActivity
Link is up at the rate of 1,000 Mbps.
Link is up at the rate of 100 Mbps.
Link is down or is up at the rate of 10 Mbps.
Amber
Green
Off
Link
Console Port
The console port on a vEdge 5000 router is accessible via the following external interface:
• An RS-232 serial interface that uses an RJ-45 connector to connect to a console management device.
See Figure 5.
Figure 5: RJ-45 Connector
The default baud rate for the console port is 115,200 baud.
Table 6 provides the pinout information for the RJ-45 console port connector.
Table 84:
DescriptionSignalPin
Request to
send
RTS Output1
No connectNC2
Transmit dataTxD Output3
Signal groundSignal
Ground
4
Hardware Installation Guide for vEdge Routers
232
vEdge 5000 Router
Ports and Connectors

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
