Cisco vEdge Series User Manual

Table 9:
StatusColorLED
• Off: System is not on
• Green: System is powered on
• Red: Power supply fault
Green/RedPower
• Off: System is not on
• Solid Green: System is fully functional and OMP connection
is in the Up state
• Blinking Green: System is booting up
• Solid Yellow: System is up but OMP connection is in the
Down state
• Solid Red: System has detected a major system level
fault—one of the necessary daemons in the system is
down (system will usually reboot shortly after this)
Green/Yellow/RedStatus (SYS)
• Off: No link and corresponding yellow LED is off
• Solid Green: 1000 Mbps link detected
• Blinking Green: 1000 Mbps link detected and link activity
GreenRJ-45 Ethernet Port
LEDs (0–4)
• Off: No link and corresponding green LED is off
• Solid Yellow: 10/100 Mbps link detected
• Blinking Yellow: 10/100 Mbps link detected and link activity
YellowRJ-45 Ethernet Port
LEDs (0–4)
Reset Button
The Reset button on the front panel is recessed, to avoid accidentally pressing it while the router is operational.
To press the Reset button, use a sharp narrow tool. Table 2 describes the effects of pressing the Reset button.
Table 10:
BehaviorPress
Duration
Pressing for two seconds resets and reboots the router.Short press
Pressing for 10 seconds resets the router and reboots it with factory default configuration.Long press
Rear Panel
The rear panel of the vEdge 100b router has a small metal-enforced hole for attaching a Kensington lock to
secure the router. See Chassis Views for the location of these components.
Hardware Installation Guide for vEdge Routers
32
vEdge 100b Router
Front and Rear Panel Components

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
