Cisco vEdge Series User Manual

Figure 6: Closing the SIM Card Holder Cover
If you need to change the SIM card later, make sure you disconnect the router's power first, before installing
the new card.
Attach the Antennas to the vEdge 100m Router
The rear panel of the vEdge 100m router has two antenna terminals. To attach the multiband antennas to the
router:
1. Screw one antenna into the terminal marked MAIN, and screw the other antenna into the terminal marked
DIV.
Figure 7: Attaching the Antennas to the Rear of the Router
1. Turn each antenna so that it is vertical. See Figure 8.
Figure 8: Turning the Antenna to a Vertical Position
Hardware Installation Guide for vEdge Routers
67
vEdge 100m Router
Install the vEdge 100m Router

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
