Citrix ADC MPX
General
• What is the recommended terminal emulator?
PuTTY.
• Which platforms support Pay‑As‑You‑Grow licenses?
Check the Citrix ADC data sheet for the updated list of platforms that support Pay‑As‑You‑Grow
licenses.
Some of the platforms that support Pay‑As‑You‑Grow licenses are listed here:
– MPX 5550 to MPX 5650
– MPX 5901 to MPX 5905 to MPX 5910
– MPX 8005 to MPX 8015
– MPX 8905 to MPX 8910 to MPX 8920 to MPX 8930
– MPX 14020 to MPX 14030 MPX 14040 MPX 14060 MPX 14080 MPX 14100
– MPX 14020‑40G to MPX 14030‑40G MPX 14040‑40G MPX 14060‑40G MPX 14080‑40G MPX
14100‑40G
– MPX 14040‑40S MPX 14060‑40S MPX 14080‑40S MPX 14100‑40S
– MPX 14030 FIPS to 14060 FIPS to 14080 FIPS
– MPX 15020 to MPX 15030 to MPX 15040 to MPX 15060 to MPX 15080 to MPX 15100
– MPX 15020‑50G to MPX 15030‑50G to MPX 15040‑50G to MPX 15060‑50G to MPX 15080‑50G
to MPX 15100‑50G
– MPX 22040 to MPX 22060 to MPX 22080 to MPX 22100 to MPX 22120
– MPX 25100‑40G to MPX 25160‑40G to MPX 25200‑40G
– T‑series platform
• Do Citrix ADC appliances support direct attach cable (DAC)?
Yes, Citrix ADC appliances support a passive DAC in release 10.5 and later.
• Which port must I insert the DAC into?
DAC is inserted into the 10G port on the appliance.
• Does the 1G port support a DAC?
No. The DAC might fit into a 1G port but is not supported.
• How can I order a DAC?
Contact your Citrix sales representative to order a DAC.
• Can I mix DAC and fiber transceivers on the same appliance?
Yes. You can mix DAC and fiber transceivers on the same appliance. Each 10G port supports
both options.
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 223
