FIGURE 3-22. SNAP RING REPLACEMENT
AFU SNAP
RING
RDU SNAP
RING
SPHERICAL
BEARING
SNAP RING
231
TABLE 3-14. SNAP RING REPLACEMENT IDENTIFICATION
Number Component
1 AFU snap ring
2 RDU snap ring
