COBHAM D-MBR 3707 User Manual

D-MBR 3707-3708 PS NFPA CLASS A SIGNAL BOOSTER
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage
Date: 17-Jan-16
www.cobham.com/wireless
Doc. No.00060CDUM Rev. 1.1 Page | 41
5.2.2.1 Operation Items
The operation options are always displayed in the window header.
Item Description
CMU/band/ Users Shows the currently selected menu item.
Send Uploads configuration changes to the Booster.
Refresh Refreshes the current screen and displayed data
CMU Reset
Click to reset the Web Access application, in case of failure or
display issues
Date and Time Access Booster Date and Time settings.
User Currently logged in authentication level and user.
Logout Click to logout current user.
5.2.2.2 Left Pane Menu Options
The left pane contains three menu items, where clicking each item invokes dedication tabs and
options:
• CMU – communication, monitoring and administrative options.
• 700-800 – band-level RF configuration, management and monitoring options
• Users – user management tools, including
Password Change.
Figure 5-7. Menu Item
User management
and password change
Communication, monitoring
and administrative options
RF configuration options
Selected menu item
