The 2110 SSB Transceiver
2110 SSB Transceiver Reference Manual 29
The and keys
Press to:
• select the item on the active line in the list
• save changes
• answer ‘yes’ to prompts
Hold to edit settings.
Press to:
• backspace over text
• remove messages on the screen
• cancel changes
• answer ‘no’ to prompts
Hold to go from any location to the home screen. If you have entered text into a
setting and want to discard the changes you made, hold .
The scroll keys
The and keys are the scroll keys. Use these keys to scroll up or down through any
kind of list, to scroll left or right over text, and to increase or decrease a value.
Interface connectors
The interface connector area comprises:
• the 6-way handset connector ( )
• the 19-way GPIO connector ( )
Antennas
The antenna area comprises:
• the antenna stud ( ) for whip antennas and the long wire antenna adaptor
• the 50 Ω connector ( ) for broadband and dipole antennas
