coM.sat ISDN Basic
created: page: file:
16/01/09 71 coMsat ISDN Basic Manual V2.7.doc
Note Protection Mark according to DIN 34!
In this way, the clarity of the presentation can be individually adjusted. The
configuration can be used to hide information that is not important at present from the
trace. However, it continues to be available for calling up and can be unhidden as
needed.
Various details and colours can be selected for
GSM Channel 1
GSM Channel 2
MODEM (does not apply to ISDN Basic)
Debug Output
ISDN Layer 1
ISDN Layer 2
ISDN Layer 3
3.3.20 Additional information
The “File“ menu lists the “New“, “Open“, “Save“ and “Save As“ menu items usually
available under Windows. These are used by the standard Windows conventions and
do not require any further explanation. As usual in Windows, the last 4 active
configurations are listed in order (most recent first). The program can be quit by
selecting the last menu entry “Exit“.
The menu item “Monitor“ and the subsequent entry “Load“ can be used to transfer
current data from the coM.sat ISDN Basic for analysis. This data can be displayed
via the ”Monitor” tab and can be saved as an ASCII or a ".cdc" file. Further
information on this is given in the ”Monitor” and ”Monitor Configuration” chapters.
The “Toolbar“ can be selected via the “View“ menu item and is positioned beneath
the menu bar and by selecting the “Status Bar“ the status bar below the main
window is hidden or revealed. Furthermore, individual cards can also be called up via
”View”.
The “Help“ menu item is available to query the current version of the coMsat.exe
application.
