4 Installation and operating information
Due to the diverse settings possible using the coMsat.exe configuration program
there is a wide range of possible applications. As it is impossible to list and describe
all these applications here, the following is limited to those currently considered the
most important.
4.1 coM.sat ISDN Basic replaces network termination
To use the coM.sat ISDN Basic as network termination, the following connection
schematic results. This can vary depending on the TC system used, although the
principle arrangement is retained. The coM.sat ISDN Basic is installed as an
exchange (NT) at the external S0 bus.
NT
PBX
NT
S0ext.
TE
TE
TE
Sync
A1
A2
Aerials
S0ext.
S0ext.
co M.s.a.t. ISDN Basic
USB
Figure 32: NT Installation
