coM.sat ISDN Basic User Manual

coM.sat ISDN Basic
created: page: file:
16/01/09 90 coMsat ISDN Basic Manual V2.7.doc
Note Protection Mark according to DIN 34!
6 Technical data
Power supply unit 12-14 V DC, max 1 A
Current consumption max 380 mA average quiet current
max 900mA operating current (2 channels active)
GSM 900/1800 Standard GSM Phase II
Voice
SMS (Receive / Send in text mode)
Transmitter power max. 2 Watt per channel (GSM 900)
max. 1 Watt per channel (GSM1800)
SIM Card 3V SIM card
Interfaces USB-B 1.1 interface connector for programming
and monitor operation, sending and receiving SMS
messages
S
0
interface (NT or TE, P-P or PMP settable, EDSS-
1 protocol, impedance 100 Ω) as RJ 45 socket
Antenna 50 Ω impedance on SMA socket
Dimensions (B x D x H) 170 x 225 x 50 mm
Weight approx. 700 gr
Temperature range 0 °C to 40° C

coM.sat ISDN Basic Specifications

General

Brand	coM.sat
Model	ISDN Basic
Category	Network Router
Language	English
