ID-FLX Lite & Telecom Global Guide
131
Setpoint group Load limit Related FW 2.5.0
Range [units] -10000 .. +10000 [-]
Default value 0 YES
Step 1
Comm object 11840 Related applications
Description
Limit to open the SPEEDSWITCH (PAGE 217).
Value of this Setpoint should be given in value of quantity without decimal point.
Example: When AIN is configured in such way that Load limit set on 5īV to maintain the value
8.54ībar, then the value inserted to this Setpoint is 854.
Reg CMP Off
6 back to List of setpoints
Setpoint group Load limit Related FW 2.5.0
Range [units] Reg Bias, LBi SpdUp/Dwn, CU AI1-CU AI9, AIO: AI1 - 4 [-]
Default value Reg Bias YES
Step -
Comm object 13068 Related applications N/A
Description
The setpoint is used for selecting what regulation will be used in AUTO mode in case automatic regulation is
disabled by R REG DISABLE (PAGE 192) Disable. The options are:
Reg Bias ā speed request will be set according to Reg Bias (page 127), this function was standard
functionality of R Reg disable LBI in previous FW versions.
SPEED UP (PAGE 189) / SPEED DOWN (PAGE 189) ā it is possible to regulate speed manually by
Speed Up (page 189) / Speed Down (page 189) even in Auto mode.
CU AI1-CU AI9, AIO: AI1 - 4 ā it is possible to regulate speed manually by analog inputs even in Auto
mode
Note: See Speed request chart (page 61).
AUT SpdReq
6 back to List of setpoints
