InteliLite4 AMF20 Global Guide
123
Alarms / Protection name
Speed
Sd Overspeed (page 560)
Sd Underspeed (page 560)
Engine protections
User Protections
InteliLite 4 allows users to configure their own protections to any analog input or binary input/output. Only one
protection of 1st level and/or one protection of 2nd level can be configured on logical binary input/output.
More than one protection can be configured on analog input. Max simultaneous number of configured user
protections is 64.
Source upon which the protection is configured can be selected. It can be any analog value or binary state.
Analog values Binary states
Analog inputs
Controller, Modules
Values
ECU, Generator, Mains, others
Statistics
Binary inputs
Controller, Modules, ECU
Binary outputs
PLC
Protection states
LBOs
Source
Type Name of activation Description
Analog
Over Limit Protection is activated if value is over limit.
Over Limit + Fls Protection is activated if value is over limit or in a fault state.
Under Limit Protection is activated if value is under limit.
Under Limit + Fls Protection is activated if value is under limit or in a fault state.
Fls only Protection is activated if value is in a fault state.
Binary
True Protection is activated if value is Logical 1.
TrueOrFls Protection is activated if value is Logical 1 or in a fault state.
False Protection is activated if value is Logical 0.
FalseOrFls Protection is activated if value is Logical 0 or in a fault state.
Protection activation
