InteliLite4 AMF20 Global Guide
461
Related FW 1.3.0 Related applications AMF,MRS
Comm object 189
Description
Binary input has the same function as Start Button on the InteliLite 4 front panel. It is evaluated in MAN
mode only.
Start Button
6 back to Logical binary inputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 190
Description
Binary input has the same function as Stop Button on the InteliLite 4 front panel. It is evaluated in MAN
Mode only.
Stop Button
6 back to Logical binary inputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1112
Description
When the first rising edge appears on the binary input, the MODE is changed to AUTO. Falling edge has
no effect and controller stays in AUTO MODE.
There is no blocking between these "Switch To" LBIs.
Example: CU is in OFF mode. LBI Switch To AUTO is activated – CU goes to AUTO Mode (LBI
stays active). Then LBI SWITCH TO MAN (PAGE 462) is activated – CU goes to MAN Mode (at this
moment, LBIs Switch To OFF and Switch To AUTO are active – CU reacts only on rising edges).
When more rising edges from "Switch To" LBIs are detected at the same time, mode is selected according
to priorities in the table below.
"GO to" control priority
Highest OFF
MAN
Lowest AUTO
Switch To AUT
6 back to Logical binary inputs alphabetically
