InteliLite4 AMF20 Global Guide
462
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1111
Description
When the first rising edge appears on the binary input, the MODE is changed to MAN. Falling edge has no
effect and controller stays in MAN MODE.
There is no blocking between these "Switch To" LBIs.
Example: CU is in OFF mode. LBI Switch To MAN is activated – CU goes to MAN Mode (LBI stays
active). Then LBI SWITCH TO AUT (PAGE 461) is activated – CU goes to AUTO Mode (at this
moment, LBIs Switch To MAN and Switch To AUTO are active – CU reacts only on rising edges).
When more rising edges from "Switch To" LBIs are detected at the same time, mode is selected according
to priorities in the table below.
"GO to" control priority
Highest OFF
MAN
Lowest AUTO
Switch To MAN
6 back to Logical binary inputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1110
Description
When the first rising edge appears on the binary input, the MODE is changed to OFF. Falling edge has no
effect and controller stays in OFF MODE.
There is no blocking between these "Switch To" LBIs.
Example: CU is in MAN mode. LBI Switch To OFF is activated – CU goes to OFF Mode (LBI stays
active). Then LBI SWITCH TO AUT (PAGE 461) is activated – CU goes to AUTO Mode (at this
moment, LBIs Switch To OFF and Switch To AUTO are active – CU reacts only on rising edges).
When more rising edges from "Switch To" LBIs are detected at the same time, mode is selected according
to priorities in the table below.
"GO to" control priority
Highest OFF
MAN
Lowest AUTO
Switch To OFF
6 back to Logical binary inputs alphabetically
